May 29, 2009 I have a 1993 toyota hilux 2.8ltr deisel and my speedo is not working how do i check if my speedo cable is not broken - Answered by a verified AU Auto Mechanic We use cookies to give you the best possible experience on our website. It's finally time to do some speedo gear corrections. W58 trans from mk3 supra n/a 4.30 final drive on ae86 195-60-14 azenis The speedo is optimistically reading about 15% over. Ie, 70kph indicated = 60kph actual. I have to find time to GPS this thing properly on the highway, but that's the gist of it. Toyota Motor Corporation's W family is a family of RWD/4WD transmissions built by Aisin.Physically, these transmissions have much in common (like the bell housing-to-body bolt pattern) with other Aisin-built transmissions, like the Jeep AX-5 and the Toyota G-series.
http://img.photobucket.com/albums/v518/Bullfrogg0/SU1HMDAwMjktMjAxMDA4MjctMTAwMC5qcGc.jpg
There would be on other part required, the square drive that drives the sensor, you could make one easy enough. Even if you just chopped the end off a broken speedo cable and soldered/JB weld it in. Hell it might not even need that much, just drop in the chopped bit. From there all that is needed is an electronic speedo in the dash and the correct wiring. It works off the original gear (screws on where the cable went) and I do believe coming from a C series like I found mine that the electric speedo from a corolla would be fine.
All this is hypothetical but I got quite a few PMs asking me how to do it due to people snapping the speedo cable looking for a superior solution. I've got nothing to try it on right now so will have to be a project at a later date.
Manual Transmission
Page
TROUBLESHOOTING MT-2
Does Toyota W-56 And W-58 Manual Speedo Drive Interchange Kit
W58 TRANSMISSION MT-3
Removal of Transmission MT-3
Components MT-5
Does Toyota W-56 And W-58 Manual Speedo Drive Interchange 4
Disassembly of Transmission MT-7
Inspection of Transmission Components MT-14
Assembly of Transmission MT-21
Installation of Transmission MT-34
TROUBLESHOOTING
Problem | Possible cause | Remedy | Page |
Hard to shift or will not shift | Splines on input shaft dirty or burred Transmission faulty | Repair as necessary Disassemble and inspect transmission | MT-3 MT-3 |
Transmission jumps out of gear | Transmission faulty | Disassemble and inspect transmission | REMOVAL OF TRANSMISSION 1. REMOVE NEGATIVE BATTERY TERMINAL WIRE 2. DRAIN COOLANT FROM RADIATOR UPPER TANK 3. REMOVE UPPER HOSE FROM RADIATOR 4. REMOVE CONSOLE BOX 5. REMOVE SHIFT LEVER FROM INSIDE OF VEHICLE 6. RAISE VEHICLE AND DRAIN TRANSMISSION OIL CAUTION: Be sure the vehicle is securely supported. 7. REMOVE STEERING GEAR HOUSING Remove the steering gear housing without disconnecting return and pressure tube, then suspend it. 8. REMOVE PROPELLER SHAFT Remove the propeller shaft and insert SST into the extension housing. SST 09325-20010 9. REMOVE EXHAUST PIPE CLAMP BOLT FROM STIFFENER PLATE 10. REMOVE SPEEDOMETER CABLE 11. DISCONNECT BACK-UP LIGHT SWITCH 12. REMOVE CLUTCH RELEASE CYLINDER CONNECTOR 13. REMOVE STARTER 14. JACK UP TRANSMISSION SLIGHTLY Raise the transmission enough to remove the weight from the rear support. 15. REMOVE ENGINE REAR MOUNTING 16. REMOVE TRANSMISSION ASSEMBLY Pull out the transmission down and toward the rear. COMPONENTS Speedometer Driven Gear Shift Lever Retainer Restrict Pin Clutch Housing Front Bearing Retainer Extension Housing Restrict Pin ! 410 <30, 40) I 'l 375 (27, 37)1 Intermediate Plate Transmission Case Output Shaft -Locking Ball -Spring ©—it Straight Screw Plug Counter Gear Reverse Idler Gear Interlock Pin Reverse Shift Arm Shift Fork Shaft No. 2 Interlock Pin Lock Washer and Bolt Slotted Spring Pin No. 3 Interlock Pin Reverse Idler Gear Shaft Stopper fkg-cm (ft-lb, N m)l : Specified torque t Non-reusable part * Precoated part COMPONENTS (Cont'd) Reverse Gear Center Bearing Retainer Speedometer Rear Bearing Drive Gear Output Shaft Synchronizer Ring 5 I Snap Ring Counter Center Bearing Outer Race Needle Roller Bearing Counter Gear I Snap Ring Counter Rear ßearing No. 3 Clutch Hub Counter 5th Gear Center Bearing Synchronizer Ring Synchronizer Ring No. 2 Clutch Hub Output Shaft No. 1 Clutch Hub Center Bearing Needle Roller Bearing Synchronizer Ring Needle Roller Bearing Synchronizer Ring Snap DISASSEMBLY OF TRANSMISSION 1. REMOVE BACK-UP LIGHT SWITCH. SPEEDOMETER DRIVEN GEAR, SHIFT LEVER RETAINER AND RESTRICT PINS 2. REMOVE CLUTCH HOUSING FROM TRANSMISSION CASE 3. REMOVE EXTENSION HOUSING (a) Remove the shift lever housing set bolt. (b) Remove the nine bolts. (c) Using a plastic hammer, tap the extension housing. (d) Disengage the shift and select lever from the shift head. (e) Pull out the extension housing. NOTE: Leave the gasket attached to the intermediate plate. 4. REMOVE FRONT BEARING RETAINER AND BEARING SNAP RINGS 5. SEPARATE INTERMEDIATE PLATE FROM TRANSMISSION CASE (a) Using a plastic hammer, carefully tap the transmission case. (b) Pull the transmission case from the intermediate plate. NOTE: Leave the gasket attached to the intermediate plate. 6. MOUNT INTERMEDIATE PLATE IN VISE (a) Use two long clutch housing bolts, plate washers and suitable nuts as shown. CAUTION: Install the plate washers In reverse of normal. Increase or decrease plate washers so that the bolt tip and the front tip surface of the nut are aligned. <b) Mount the intermediate plate in a vise. 7. REMOVE LOCKING BALL AND SPRING (a) Using SST, remove the four plugs. SST 09313-30021 (b) Using a magnetic finger, remove the three springs and balls. 8. REMOVE SHIFT FORKS, SHIFT FORK SHAFTS AND REVERSE IDLER GEAR (a) Pry out the lock washers of No. 1 and No. 2 shift fork, and remove the two set bolts. (b) Using two screwdrivers and a hammer, tap out the two snap rings of No. 1 and No. 2 fork shafts. (c) Remove the reverse idler gear stopper. (d) Remove the reverse idler gear and shaft. (e) Remove No. 1 shift fork and shaft. (f) Using a magnetic finger, remove No. 1 and No. 2 interlock pins. (g) Remove No. 2 shift fork and shaft. (h) Using a magnetic finger, remove No. 3 interlock pin. (i) Using a pin punch and hammer, drive out No. 3 fork shaft pin. (k) Remove No. 3 shift fork. No. 3 fork shaft and reverse shift arm with the pin. 9. REMOVE SPEEDOMETER DRIVE GEAR Pry out both ends of the clip and remove the drive gear. ! 10. MEASURE COUNTER FIFTH GEAR THRUST CLEARANCE Using a feeler gauge, measure the counter 5th gear thrust clearance. (0.0039 - 0.0161 in.) Maximum clearance: 0.46 mm (0.0181 in.) 11. REMOVE COUNTER REAR BEARING. SPACER. COUNTER FIFTH GEAR AND NEEDLE ROLLER BEARING (a) Using snap ring pliers, remove the snap ring. (b) Using SST, remove the rear bearing, spacer. 5th gear and bearing. SST 09213-36020 CAUTION: Be careful not to catch the output shaft rear bearing roller on the counter 5th gear. (c) Remove the spacer. 12. REMOVE NO. 3 HUB SLEEVE ASSEMBLY (a) Using two screwdrivers and a hammer, tap out the snap ring. (b) Using SST, remove No. 3 clutch hub. SST 09950-20016 CAUTION: Latch the claw of the SST onto the clutch hub. not the shifting key retainer.
13. REMOVE OUTPUT SHAFT REAR BEARING AND FIFTH GEAR (a) Using two screwdrivers and a hammer, tap out the snap ring. (b) Using SST, remove the rear bearing and 5th gear. SST 09312-20011 14. REMOVE REVERSE GEAR (a) Using snap ring pliers, remove the snap ring. (b) Using SST, remove the reverse gear. SST 09950-20016 15. REMOVE CENTER BEARING RETAINER (a) Using a torx socket wrench, unscrew the torx screws and remove the retainer. (b) Using snap ring pliers, remove the snap ring. 16. REMOVE OUTPUT SHAFT AND COUNTER GEAR ASA UNIT FROM INTERMEDIATE PLATE(a) Remove the output shaft, input shaft and counter gear as a unit from the intermediate plate by pulling on the counter gear and tapping on the intermediate plate with a plastic hammer. (b) Remove the input shaft from output shaft. 17. MEASURE EACH GEAR THRUST CLEARANCE Using a feeler gauge, measure the thrust clearance of each gear. Standard clearance: Maximum clearance: 0.10 - 0.25 mm (0.0039 - 0.0098 in.) 0.30 mm (0.0118 in.) Torx Socket Wrench Torx Socket Wrench *WOOM 18. REMOVE OUTPUT SHAFT CENTER BEARING AND FIRST GEAR ASSEMBLY (a) Shift No. 1 hub sleeve onto the 2nd gear. (b) Using a press, remove the center bearing, 1st gear, needle roller bearing, inner race and synchronizer ring. 19. REMOVE LOCKING BALL 20. REMOVE NO. 1 HUB SLEEVE ASSEMBLY, SECOND GEAR AND NEEDLE ROLLER BEARING Using a press, remove the parts from the shaft as an assembly. 21. REMOVE NO. 2 HUB SLEEVE ASSEMBLY AND THIRD GEAR (a) Using snap ring pliers, remove the snap ring. (b) Using a press, remove No. 2 hub sleeve, synchronizer ring and 3rd gear. |
